加工定制	否
精度等級	5%
最大工作壓力	1MPa（Mpa）
品牌	DWYER
型號	PTGD-SC05A

產品名稱:  PTGD系列壓差表
產品型號:  PTGD系列

產品介紹The Series PTGD Differential Pressure Piston-Type Gage can be used to measure the pressure drop across filters, strainers, pump performance testing, and heat exchanger pressure drop monitoring. Its simple, rugged design possesses weather and corrosion resistant gage front with a shatter resistant lens. The Series PTGD contains a piston-sensing element which provides different differential pressure ranges with full-scale accuracies of ±2%. Constructed with aluminum or 316SS and available with two 1/4" female NPT end connections, the Series PTGD provides over-range protection rated to 3000 psig (200 bar) or 6000 psig (400 bar) depending on model. Standard models come with in-line connections. Back or bottom connections are also available.技術參數介質: Compatible gases and liquids.材質: Gage Body: Aluminum or 316 SS; Piston: Aluminum or 316 SS; Spring: 302 SS; Seals: Buna-N (standard); PTFE, Ceramic Magnet; Dial Case: Nylon 6 30% glass filled gage case.Window: Acrylic.精度: ±2% FS ascending.耐壓: 3000 psi (206 bar) for aluminum body; 6000 psi (413 bar) for SS body.尺寸: 2.5" (63 mm) or 4.5" (115 mm).安裝方向: Mount in any poSITIon.過程連接: 1/4" female NPT end connections standard; 1/4" female NPT back or bottom connections available. All styles available with 1/4" BSP.重量: Aluminum: Aluminum: 2.5" 0.88 lb (399 g); 4.5" 1.35 lbs (612 g); Stainless Steel: 2.5" 1.75 lbs (794 g); 4.5" 2.3 lbs (1.04 kg). 1-9/32 選型表：

型號	描述
PTGD-AA01A	2.5"表盤,鋁殼,范圍 0-5 psid(0.25bar).
PTGD-AA02A	2.5"表盤,鋁殼,范圍  0-10 psid(0.75bar).
PTGD-AA03A	2.5"表盤,鋁殼,范圍  0-15 psid(1bar).
PTGD-AA04A	2.5"表盤,鋁殼,范圍  0-20 psid(1.6bar).
PTGD-AA05A	2.5"表盤,鋁殼,范圍  0-25 psid(1.6bar).
PTGD-AA06A	2.5"表盤,鋁殼,范圍 0-30 psid(2bar).
PTGD-AA07A	2.5"表盤,鋁殼,范圍  0-40 psid(3bar).
PTGD-AA08A	2.5"表盤,鋁殼,范圍  0-50 psid(3.5bar).
PTGD-AA09A	2.5"表盤,鋁殼,范圍  0-60 psid(4bar).
PTGD-AA10A	2.5"表盤,鋁殼,范圍  0-80 psid(5.5bar).
PTGD-AA11A	2.5"表盤,鋁殼,范圍  0-100 psid(7bar).
PTGD-AA12A	2.5"表盤,鋁殼,范圍  0-150 psid(10bar).
PTGD-SA01A	2.5"表盤,不銹鋼殼,范圍 0-5 psid(0.25bar).
PTGD-SA02A	2.5"表盤,不銹鋼殼,范圍0-10 psid(0.75bar).
PTGD-SA03A	2.5"表盤,不銹鋼殼,范圍 0-15 psid(1bar).
PTGD-SA04A	2.5"表盤,不銹鋼殼,范圍 0-20 psid(1.6bar).
PTGD-SA05A	2.5"表盤,不銹鋼殼,范圍0-25 psid(1.6bar).
PTGD-SA06A	2.5"表盤,不銹鋼殼,范圍 0-30 psid(2bar).
PTGD-SA07A	2.5"表盤,不銹鋼殼,范圍 0-40 psid(3bar).
PTGD-SA08A	2.5"表盤,不銹鋼殼,范圍 0-50 psid(3.5bar).
PTGD-SA09A	2.5"表盤,不銹鋼殼,范圍 0-60 psid(4bar).
PTGD-SA10A	2.5"表盤,不銹鋼殼,范圍 0-80 psid(5.5bar).
PTGD-SA11A	2.5"表盤,不銹鋼殼,范圍 0-100 psid(7bar).
PTGD-SA12A	2.5"表盤,不銹鋼殼,范圍 0-150 psid(10bar).
PTGD-AC01A	4.5"表盤,鋁殼,范圍 0-5 psid(0.25bar).
PTGD-AC02A	4.5"表盤,鋁殼,范圍  0-10 psid(0.75bar).
PTGD-AC03A	4.5"表盤,鋁殼,范圍  0-15 psid(1bar).
PTGD-AC04A	4.5"表盤,鋁殼,范圍  0-20 psid(1.6bar).
PTGD-AC05A	4.5"表盤,鋁殼,范圍  0-25 psid(1.6bar).
PTGD-AC06A	4.5"表盤,鋁殼,范圍 0-30 psid(2bar).
PTGD-AC07A	4.5"表盤,鋁殼,范圍  0-40 psid(3bar).
PTGD-AC08A	4.5"表盤,鋁殼,范圍  0-50 psid(3.5bar).
PTGD-AC09A	4.5"表盤,鋁殼,范圍  0-60 psid(4bar).
PTGD-AC10A	4.5"表盤,鋁殼,范圍  0-80 psid(5.5bar).
PTGD-AC11A	4.5"表盤,鋁殼,范圍  0-100 psid(7bar).
PTGD-AC12A	4.5"表盤,鋁殼,范圍  0-150 psid(10bar).
PTGD-SC01A	4.5"表盤,不銹鋼殼,范圍 0-5 psid(0.25bar).
PTGD-SC02A	4.5"表盤,不銹鋼殼,范圍0-10 psid(0.75bar).
PTGD-SC03A	4.5"表盤,不銹鋼殼,范圍 0-15 psid(1bar).
PTGD-SC04A	4.5"表盤,不銹鋼殼,范圍 0-20 psid(1.6bar).
PTGD-SC05A	4.5"表盤,不銹鋼殼,范圍0-25 psid(1.6bar).
PTGD-SC06A	4.5"表盤,不銹鋼殼,范圍 0-30 psid(2bar).
PTGD-SC07A	4.5"表盤,不銹鋼殼,范圍 0-40 psid(3bar).
PTGD-SC08A	4.5"表盤,不銹鋼殼,范圍 0-50 psid(3.5bar).
PTGD-SC09A	4.5"表盤,不銹鋼殼,范圍 0-60 psid(4bar).
PTGD-SC10A	4.5"表盤,不銹鋼殼,范圍 0-80 psid(5.5bar).
PTGD-SC11A	4.5"表盤,不銹鋼殼,范圍 0-100 psid(7bar).
PTGD-SC12A	4.5"表盤,不銹鋼殼,范圍 0-150 psid(10bar).

舉例	PTGD	A	A	1	A	N	Series PTGD-AA01A-N 2.5" Differential Pressure Piston-Type Gage, aluminum wetted parts, range 5 psid/0.25 bar, 1/4" female NPT inline connection, with neoprene seals.
系列	PTGD						Differential Pressure Piston-Type Gage
接液材質		A					Aluminum
		S					316 Stainless Steel
尺寸			A				2.5"
			C				4.5"
范圍				1			5 psid/0.25 bar
				2			10 psid/0.75 bar
				3			15 psid/1.0 bar
				4			20 psid/1.6 bar
				5			25 psid/1.6 bar
				6			30 psid/2.0 bar
				7			40 psid/3.0 bar
				8			50 psid/3.5 bar
				9			60 psid/4.0 bar
				10			80 psid/5.5 bar
				11			100 psid/7.0 bar
				12			150 psid/10.0 bar
				13			5 psid/0.25 kg/cm²
				14			10 psid/0.75 kg/cm²
				15			15 psid/1.0 kg/cm²
				16			20 psid/1.6 kg/cm²
				17			25 psid/1.6 kg/cm²
				18			30 psid/2.0 kg/cm²
				19			40 psid/3.0 kg/cm²
				20			50 psid/3.5 kg/cm²
				21			60 psid/4.0 kg/cm²
				22			80 psid/5.5 kg/cm²
				23			100 psid/7.0 kg/cm²
				24			150 psid/10.0 kg/cm²
				25			5 psid/25 kPa
				26			10 psid/75 kPa
				27			15 psid/100 kPa
				28			20 psid/160 kPa
				29			25 psid/160 kPa
				30			30 psid/200 kPa
				31			40 psid/300 kPa
				32			50 psid/350 kPa
				33			60 psid/400 kPa
				34			80 psid/550 kPa
				35			100 psid/700 kPa
				36			150 psid/1000 kPa
連接					A		1/4" Female NPT Inline
					B		1/4" Female NPT Rear
					C		1/4" Female NPT Bottom
					D		1/4" Female BSP Inline
					E		1/4" Female BSP Rear
					F		1/4" Female BSP Bottom
其它可選項						N	Neoprene Seals
						PY	Glycerine Fill
						PF	Pointer Follower
						RP	Reverse Port
						SP1	1 SPST DIN Plug
						SP2	1 SPDT DIN Plug
						V	FKM Seals
